Product Details

Model NO.

YJLV22YJV32

Current

AC Cable

Insulation Material

XLPE

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Red Copper Wire

Certification

ISO, CCC, CE, RoHS, VDE

Model

YJV

Brand

Guowang

Operating Temperature

90ºC

Ambient Temperature

Not Be Lower Than-15ºC

Laying Temperature

Not Be Lower Than 0ºC

Radius Bend

15D

Transport Package

Iron Tray Packing

Specification

As per the customer request

Trademark

GUOWANG

Origin

China

HS Code

8544492100

Production Capacity

500000/Week

Packaging & Delivery

Package Size

2100.00cm * 1100.00cm * 1050.00cm

Package Gross Weight

200.000kg

Product Description

System
This product is suitable for transmitting electric energy in power lines with AC 50Hz and rated voltage 0.6/1kV (system maximum voltage 1.2kV).
Occasion
Fixed laying in metallurgy, electric power, construction and other industries indoors, cable trenches, pipelines, direct burial and other places that do not need to withstand mechanical external force.
Features
The raw materials for product production are widely sourced and cheap, and are easy to process and manufacture.
The product is insulated with cross-linked polyethylene. Compared with PVC insulated cables, it has better insulation performance and canwithstand extremely high working temperatures, up to 90 degrees.
Implementation standards
GB/T 12706.1-2020 Extruded insulated power cables and accessories with rated voltage 1kV (Um=1.2kV) to 35kV (Um=40.5kV) Part 1: Rated voltage 1kV (Um=1.2kV) and 3kV (Um=3.6kV ) )cable
additional standards
Usage features
Rated voltage
The rated voltage of power frequency AC is 0.6/1kV, and the maximum voltage of the AC system should not exceed 1.2kV.
Operating temperature
The maximum allowable long-term operating temperature of the cable conductor is 90°C; during a short circuit, the maximum temperature of the cable conductor does not exceed 250°C and the duration does not exceed 5 seconds.
ambient temperature
Minimum working environment temperature -15ºC.
Laying temperature
The laying temperature of cables should not be lower than 0ºC.
radius bend
The bending radius of single-core cables should be no less than 20 times the outer diameter of the cable, and the bending radius of multi-core cables should be no less than 15 times the outer diameter of the cable.
Product Identification
Core
1.Color identification When multi-core cables are marked with different colors, they must comply with the following regulations: 2-core cable: red, blue; 3-core cable: yellow, green, red; 4-core cable: yellow, green, red, blue; 5-core cable Cable: yellow, green, red, blue, black (or determined by negotiation between the supplier and the buyer). The colors red, yellow and green are used for the main wire core. Blue is used for the neutral core. In order to avoid confusion with other colors, it is recommended to use light blue.
2. Digital identification When multi-core cables use digital identification, they must comply with the following regulations: 2-core cable: 0, 1; 3-core cable: 1, 2, 3; 4-core cable: 0, 1, 2, 3; 5-core cable :0,1,2,3,4. The numbers 1, 2, and 3 are used for the main core, and 0 is used for the neutral core. In a 5-core cable, the number “4” refers to the specific purpose conductor (including the grounding conductor). When the insulated cores are marked with numbers, the insulation should be of the same color and arranged according to the numbers. Numbers should be printed on the surface of the insulated core with Arabic numerals. The color of the numbers should be the same and have obvious contrast with the insulation color and the writing should be clear; the number signs should be repeated at equal intervals along the insulated core, and two adjacent sets of number signs should be Invert each other. When the logo consists of a single number, a dash should be placed below the number. If the The logo consists of two numbers, it should be arranged up and down and a dash should be placed below the subsequent numbers. The spacing between two adjacent sets of digital logos is d. Should be no larger than 50mm.
outer cortex
The outer sheath of the cable is usually black, but it can also be in colors other than black according to the manufacturer or buyer’s agreement to adapt to its use environment. The cable should have continuous identification of the manufacturer’s name, product model and rated voltage . The manufacturer’s name identification can be Duplicate identification of manufacturer or trademark. The printed logo should be scratch-resistant and not fall off, and the printed content on the surface should be clearly legible. Note: The logo on the surface of the sheath can also add other logo contents according to the habits of the user or manufacturer.
Delivery and Tolerance
Delivery Length
Cables weighing less than 80kg are allowed to be delivered in coils, and the delivery length of short-segment cables should not exceed 5% of the total delivery length, or cables of any length can be delivered according to mutual agreement.
Length error
Delivery length measurement error is ±0.5%

Rated voltage	No,of CORES	core ×cross secticn (MM)	CONDUCTOR	CORE DIANETER (MM2)	INSULATION THCKNESS (MM)	BELT (MM)	JACKET THICKNESS (MM)	Reference outer diameter (MM)	Reference weight (kg/km)	DC RESISTANCE (Ω/KM)
0.6/1KV	2	2×1.5	1/1.38	1.38	0.7	20×0.20	1.8	9.8	122.1	12.1
	2	2×2.5	1/1.78	1.78	0.7	20×0.20	1.8	10.6	151.8	7.41
	2	2×4	1/2.25	2.25	0.7	20×0.20	1.8	11.6	193.9	4.61
	2	2×6	1/2.76	2.76	0.7	20×0.20	1.8	12.6	245.8	3.08
	2	2×10	7/1.35	4.05	0.7	30×0.20	1.8	15.2	352.1	1.83
	2	2×16	7/1.66	4.98	0.7	35×0.20	1.8	17.2	479.7	1.15
	2	2×25	7/2.14	6.42	0.9	40×0.20	1.8	20.6	733	0.727
	2	2×35	7/2.52	7.56	0.9	50×0.20	1.8	23	959.5	0.524
	2	2×50	10/2.52	5.7×13.5	1	40×0.20	1.8	19.6	1083.6	0.387
	2	2×70	14/2.52	7.0×15.6	1.1	45×0.20	1.8	22.6	1473.8	0.268
	2	2×95	19/2.52	8.3×18.0	1.1	55×0.20	1.9	25.4	1975.8	0.193
	2	2×120	24/2.52	8.9×20.8	1.2	60×0.20	2	27.2	2461.9	0.153
	2	2×150	30/2.52	10.0×23.1	1.4	60×0.20	2.2	30.6	3066.9	0.124
	2	2×185	37/2.52	11.1×25.7	1.6	60×0.20	2.3	33.8	3765.6	0.0991
	2	2×240	48/2.52	12.5×29.1	1.7	60×0.20	2.5	37.4	4833.1	0.0754
	2	2×300	61/2.52	15.0×32.2	1.8	60×0.20	2.6	43	6091.7	0.0601
	3	3×1.5	1/1.38	1.38	0.7	20×0.20	1.8	10.2	144.1	12.1
	3	3×2.5	1/1.78	1.78	0.7	20×0.20	1.8	11.1	182.9	7.41
	3	3×4	1/2.25	2.25	0.7	20×0.20	1.8	12.2	240	4.61
	3	3×6	1/2.76	2.76	0.7	20×0.20	1.8	13.3	311.6	3.08
	3	3×10	7/1.35	4.05	0.7	30×0.20	1.8	16.1	456.4	1.83
	3	3×16	7/1.66	4.98	0.7	35×0.20	1.8	18.2	630.8	1.15
	3	3×25	7/2.14	6.42	0.9	45×0.20	1.8	21.9	981.5	0.727
	3	3×35	7/2.52	7.56	0.9	50×0.20	1.8	24.5	1298	0.524
	3	3×50	10/2.52	7.0×11.5	1	50×0.20	1.8	23.2	1578.5	0.387
	3	3×70	14/2.52	8.0×13.7	1.1	55×0.20	1.9	25.9	2158	0.268
	3	3×95	19/2.52	9.5×15.8	1.1	60×0.20	2	29.3	2902.1	0.193
	3	3×120	24/2.52	10.8×18.6	1.2	60×0.20	2.1	32.7	3636.5	0.153
	3	3×150	30/2.52	12.5×20.5	1.4	60×0.20	2.3	37.5	4537.4	0.124
	3	3×185	37/2.52	14.3×23.3	1.6	60×0.20	2.4	42.3	5584.6	0.0991
	3	3×240	48/2.52	16.3×26.2	1.7	60×0.20	2.6	47.4	7178.8	0.0754
	3	3×300	61/2.52	18.0×29.8	1.8	60×0.20	2.7	51.6	9012.4	0.0601
	4	4×1.5	1/1.38	1.38	0.7	20×0.20	1.8	11	169.8	12.1
	4	4×2.5	1/1.78	1.78	0.7	20×0.20	1.8	11.9	221.2	7.41
	4	4×4	1/2.25	2.25	0.7	20×0.20	1.8	13.2	293.9	4.61
	4	4×6	1/2.76	2.76	0.7	20×0.20	1.8	14.4	385.7	3.08
	4	4×10	7/1.35	4.05	0.7	35×0.20	1.8	17.5	572.6	1.83
	4	4×16	7/1.66	4.98	0.7	40×0.20	1.8	19.9	800	1.15
	4	4×25	7/2.14	6.42	0.9	50×0.20	1.8	24	1254.7	0.727
	4	4×35	7/2.52	7.56	0.9	60×0.20	1.8	26.9	1667.3	0.524
	4	4×50	10/2.52	7.5×10.5	1	55×0.20	1.8	25.1	2058.2	0.387
	4	4×70	14/2.52	9.1×12.5	1.1	60×0.20	2	29.5	2848.2	0.268
	4	4×95	19/2.52	11.0×13.3	1.1	60×0.20	2.1	33.8	3838.2	0.193
	4	4×120	24/2.52	12.0×17.0	1.2	60×0.20	2.3	36.9	4817.3	0.153
	4	4×150	30/2.52	13.9×19.7	1.4	60×0.20	2.4	42.1	5987.1	0.124
	4	4×185	37/2.52	15.2×21.2	1.6	60×0.20	2.6	46.3	7375.8	0.0991
	4	4×240	48/2.52	17.3×24.3	1.7	60×0.20	2.8	51.7	9480.4	0.0754
	4	4×300	61/2.52	19.5×27.9	1.8	60×0.20	3	57.4	11951.3	0.0601
	5	5×1.5	1/1.38	1.38	0.7	20×0.20	1.8	11.8	197.6	12.1
	5	5×2.5	1/1.78	1.78	0.7	20×0.20	1.8	12.8	260.3	7.41
	5	5×4	1/2.25	2.25	0.7	20×0.20	1.8	14.2	350.8	4.61
	5	5×6	1/2.76	2.76	0.7	20×0.20	1.8	15.5	463.3	3.08
	5	5×10	7/1.35	4.05	0.7	40×0.20	1.8	19.1	695.7	1.83
	5	5×16	7/1.66	4.98	0.7	45×0.20	1.8	21.8	977.7	1.15
	5	5×25	7/2.14	6.42	0.9	55×0.20	1.8	26.3	1538.7	0.727
	5	5×35	7/2.52	7.56	0.9	60×0.20	1.8	29.6	2052.9	0.524
	5	5×50	10/2.52	4.8×14.2	1	60×0.20	1.9	27.4	2549.7	0.387
	5	5×50	10/2.52	8.4	1	60×0.20	1.9	27.4	2549.7	0.387
	5	5×70	14/2.52	5.7×16.8	1.1	60×0.20	2.1	31.7	3523.7	0.268
	5	5×70	14/2.52	10	1.1	60×0.20	2.1	31.7	3523.7	0.268
	5	5×95	19/2.52	6.7×19.6	1.1	60×0.20	2.2	35.5	4744	0.193
	5	5×95	19/2.52	11.6	1.1	60×0.20	2.2	35.5	4744	0.193
	5	5×120	24/2.52	7.9×21.9	1.2	60×0.20	2.4	40.2	5972.8	0.153
	5	5×120	24/2.52	13	1.2	60×0.20	2.4	40.2	5972.8	0.153
5	5×150	30/2.52	8.5×24.6	1.4	60×0.20	2.6	44.4	7425.2	0.124
5	5×150	30/2.52	14.6	1.4	60×0.20	2.6	44.4	7425.2	0.124
5	5×185	37/2.52	9.4×27.2	1.6	60×0.20	2.8	49.2	9151.1	0.0991
5	5×185	37/2.52	16.2	1.6	60×0.20	2.8	49.2	9151.1	0.0991
5	5×240	48/2.52	10.8×31.0	1.7	60×0.20	3	55.2	11768.5	0.0754
5	5×240	48/2.52	18.5	1.7	60×0.20	3	55.2	11768.5	0.0754
5	5×300	61/2.52	12.2×34.4	1.8	60×0.20	3.2	61	14833.3	0.0601
5	5×300	61/2.52	20.6	1.8	60×0.20	3.2	61	14833.3	0.0601
5	3×4+1×2.5	1/2.25	2.25	0.7	20×0.20	1.8	12.9	253.2	4.61
5	3×4+1×2.5	1/1.78	1.78	0.7	20×0.20	1.8	12.9	253.2	4.61
5	3×4+2×2.5	1/2.25	2.25	0.7	20×0.20	1.8	13.7	268.8	4.61
		1/1.78	1.78	0.7
		1/1.78	1.78	0.7
4	3×6+1×4	1/2.76	2.76	0.7	20×0.20	1.8	14.1	326.9	3.08
4	3×6+1×4	1/2.25	2.25	0.7	20×0.20	1.8	14.1	326.9	3.08
5	3×6+2×4	1/2.76	2.76	0.7	20×0.20	1.8	15	347	3.08
		1/2.25	2.25	0.7
		1/2.25	2.25	0.7
4	3×10+1×6	7/1.35	4.05	0.7	35×0.20	1.8	16.9	525.3	1.83
4	3×10+1×6	7/1.04	3.12	0.7	35×0.20	1.8	16.9	525.3	1.83
5	3×10+2×6	7/1.35	4.05	0.7	35×0.20	1.8	18	602.8	1.83
		7/1.04	3.12	0.7
		7/1.04	3.12	0.7
4	3×16+1×10	7/1.66	4.98	0.7	40×0.20	1.8	19.3	744.3	1.15
4	3×16+1×10	7/1.35	4.05	0.7	40×0.20	1.8	19.3	744.3	1.15
5	3×16+2×10	7/1.66	4.98	0.7	40×0.20	1.8	20.7	865.1	1.15
		7/1.35	4.05	0.7
		7/1.35	4.05	0.7
4	3×25+1×16	7/2.14	6.42	0.9	50×0.20	1.8	23	1142.9	0.727
4	3×25+1×16	7/1.66	4.98	0.7	50×0.20	1.8	23	1142.9	0.727
5	3×25+2×16	7/2.14	6.42	0.9	50×0.20	1.8	24.5	1314.5	0.727
		7/1.66	4.98	0.7
		7/1.66	4.98	0.7
4	3×35+1×16	7/2.52	7.56	0.9	55×0.20	1.8	25.2	1451.1	0.524
4	3×35+1×16	7/1.66	4.98	0.7	55×0.20	1.8	25.2	1451.1	0.524
5	3×35+2×16	7/2.52	7.56	0.9	55×0.20	1.8	26.4	1616.6	0.524
		7/1.66	4.98	0.7
		7/1.66	4.98	0.7
4	3×50+1×25	10/2.52	7.2×10.8	1	55×0.20	1.8	25.5	1839.9	0.387
4	3×50+1×25	7/2.16	6	0.9	55×0.20	1.8	25.5	1839.9	0.387
5	3×50+2×25	10/2.52	5.0×14.3	1	55×0.20	1.8	25.1	2077.1	0.387
		7/2.16	6	0.9
		7/2.16	6	0.9
4	3×70+1×35	14/2.52	9.0×13.0	1.1	60×0.20	1.9	30.3	2523	0.268
4	3×70+1×35	7/2.52	7	0.9	60×0.20	1.9	30.3	2523	0.268
5	3×70+2×35	14/2.52	6.0×16.8	1.1	60×0.20	2	28.9	2845	0.268
		7/2.52	7	0.9
		7/2.52	7	0.9
4	3×95+1×50	19/2.52	10.7×14.5	1.1	60×0.20	2.1	34.6	3428.7	0.193
4	3×95+1×50	10/2.52	8.4	1	60×0.20	2.1	34.6	3428.7	0.193
5	3×95+2×50	19/2.52	7.2×19.7	1.1	60×0.20	2.1	33	3871.9	0.193
		10/2.52	8.4	1
		10/2.52	7.1×11.5	1
4	3×120+1×70	24/2.52	11.5×17.3	1.2	60×0.20	2.2	37.1	4338.4	0.153
4	3×120+1×70	14/2.52	10	1.1	60×0.20	2.2	37.1	4338.4	0.153
5	3×120+2×70	24/2.52	8.0×22.1	1.2	60×0.20	2.3	37.1	4994.5	0.153
		14/2.52	10	1.1
		14/2.52	7.8×13.1	1.1
4	3×150+1×70	30/2.52	13.2×19.4	1.4	60×0.20	2.3	42.2	5231.4	0.124
4	3×150+1×70	14/2.52	10	1.1	60×0.20	2.3	42.2	5231.4	0.124
5	3×150+2×70	30/2.52	9.1×24.3	1.4	60×0.20	2.4	40.3	5867.5	0.124
		14/2.52	10	1.1
		14/2.52	7.8×13.1	1.1
4	3×185+1×95	37/2.52	15.0×22.3	1.6	60×0.20	2.5	47.6	6540.7	0.0991
4	3×185+1×95	19/2.52	11.6	1.1	60×0.20	2.5	47.6	6540.7	0.0991
5	3×185+2×95	37/2.52	10.2×27.2	1.6	60×0.20	2.5	45.1	7383.7	0.0991
		19/2.52	11.6	1.1
		19/2.52	9.2×14.7	1.1
4	3×240+1×120	48/2.52	17.7×23.7	1.7	60×0.20	2.6	54.5	8370.8	0.0754
4	3×240+1×120	24/2.52	13	1.2	60×0.20	2.6	54.5	8370.8	0.0754
5	3×240+2×120	48/2.52	11.5×29.2	1.7	60×0.20	2.7	50	9436.1	0.0754
		24/2.52	13	1.2
		24/2.52	9.9×16.4	1.2
4	3×300+1×150	61/2.52	19.2×28.3	1.8	60×0.20	2.8	58.9	10508	0.0601
4	3×300+1×150	30/2.52	14.6	1.4	60×0.20	2.8	58.9	10508	0.0601
5	3×300+2×150	61/2.52	13.0×33.2	1.8	60×0.20	2.9	55.6	11860.4	0.0601
		30/2.52	14.6	1.4
		30/2.52	10.6×17.9	1.4
5	4×4+1×2.5	1/2.25	2.25	0.7	20×0.20	1.8	13.9	309.8	4.61
5	4×4+1×2.5	1/1.78	1.78	0.7	20×0.20	1.8	13.9	309.8	4.61
5	4×6+1×4	1/2.76	2.76	0.7	20×0.20	1.8	15.3	404.1	3.08
5	4×6+1×4	1/2.25	2.25	0.7	20×0.20	1.8	15.3	404.1	3.08
5	4×10+1×6	7/1.35	4.05	0.7	35×0.20	1.8	18.5	648.8	1.83
5	4×10+1×6	7/1.04	3.12	0.7	35×0.20	1.8	18.5	648.8	1.83
5	4×16+1×10	7/1.66	4.98	0.7	45×0.20	1.8	21.2	921.3	1.15
5	4×16+1×10	7/1.35	4.05	0.7	45×0.20	1.8	21.2	921.3	1.15
5	4×25+1×16	7/2.14	6.42	0.9	55×0.20	1.8	25.4	1428.5	0.727
5	4×25+1×16	7/1.66	4.98	0.7	55×0.20	1.8	25.4	1428.5	0.727
5	4×35+1×16	7/2.52	7.56	0.9	60×0.20	1.8	28	1836.6	0.524
5	4×35+1×16	7/1.66	4.98	0.7	60×0.20	1.8	28	1836.6	0.524
5	4×50+1×25	10/2.52	5.5×13.4	1	55×0.20	1.9	26.3	2320.3	0.387
5	4×50+1×25	7/2.16	6	0.9	55×0.20	1.9	26.3	2320.3	0.387
5	4×70+1×35	14/2.52	6.7×15.8	1.1	60×0.20	2	30.3	3179.6	0.268
5	4×70+1×35	7/2.52	7	0.9	60×0.20	2	30.3	3179.6	0.268
5	4×95+1×50	19/2.52	7.7×18.3	1.1	60×0.20	2.2	34.2	4316.2	0.193
5	4×95+1×50	10/2.52	8.4	1	60×0.20	2.2	34.2	4316.2	0.193
5	4×120+1×70	24/2.52	9.5×20.8	1.2	60×0.20	2.3	40.1	5494.4	0.153
5	4×120+1×70	14/2.52	10	1.1	60×0.20	2.3	40.1	5494.4	0.153
5	4×150+1×70	30/2.52	10.0×22.9	1.4	60×0.20	2.5	42.3	6647.9	0.124
5	4×150+1×70	14/2.52	10	1.1	60×0.20	2.5	42.3	6647.9	0.124
5	4×185+1×95	37/2.52	10.8×25.6	1.6	60×0.20	2.6	46.7	8254.5	0.0991
5	4×185+1×95	19/2.52	11.6	1.1	60×0.20	2.6	46.7	8254.5	0.0991
5	4×240+1×120	48/2.52	12.6×28.9	1.7	60×0.20	2.9	52.6	10616.3	0.0754
5	4×240+1×120	24/2.52	13	1.2	60×0.20	2.9	52.6	10616.3	0.0754
5	4×300+1×150	61/2.52	13.8×32.2	1.8	60×0.20	3.1	57.6	13352.6	0.0601
5	4×300+1×150	30/2.52	14.6	1.4	60×0.20	3.1	57.6	13352.6	0.0601
