2 Core 6mm 2*6mm UV Resistant Solar DC Cable

2 Core 6mm 2*6mm UV Resistant Solar DC Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Solar cable

Sheath Material

Crosslinking

Insulating Material

Xlpo

Conductor Type

Stranded

Brand

Chubin

Certification

Wire Core Material

Tinned Wire

Type

Insulated

Conductor Material

Copper

Range of Application

Lsoh

Insulation Material

Crosslinking

Rated Voltage

0.6/1kv

Number of Cores

Insulation

PVC

Packing

Roll

Conductor

Copper

MOQ

1000 Meters

Length

Lengths Customize

Product Name

Solar Cable

Rated Temperature

70′c

Transport Package

Cartons, Wooden Wheels, Soft

Trademark

Chunbin

Origin

Luoyang, Henan

Production Capacity

30, 000m/Week

Product Description

Products Description

Conductor	Tinned annealed copper wire
Insulation	Crosslinked material (XLPO, etc)
Application	Photovoltaic Power
Rated Voltage	0.6-1KV
Number of Cores	One Core, twin cores
MOQ	500 Meters

1. Strong bending resistance, strict control of finished product quality, with strong flexibility. 2. It has the characteristics of ultraviolet resistance, flame retardant, aging resistance, wear resistance, etc., and the service life is more than 25 years. 3. High strength, corrosion resistance, with strong practicability.

Parameter

Cross section (n×mm^2)	Conductor (mm)	Outer (mm)	Current-carrying capacity [A] at 60ºC	Conductor resistance kΩ/km at 20ºC	Cable Code
1×1.5	1.4	4.2	30	13.7	PV302515
1×2.5	1.8	5	42	8.21	PV502525
1×4.0	2.2	5.2	55	5.09	PV562940
1×6.0	2.8	5.8	70	3.39	PV842960
1×10.0	4.0	7.5	98	1.95	PV142301
1×16.0	5.0	8.9	132	1.24	PV228301
1×25.0	6.2	10.9	176	0.795	PV361302
1×35.0	7.3	12.8	218	0.565	PV525303
1×50.0	8.8	14.3	280	0.393	PV720305
1×70.0	11.0	16.5	350	0.277	PV988307
1×95.0	12.3	18.2	410	0.210	PV134930
1×120.0	14.1	20.2	480	0.164	PV169130

Packing & Delivery

Package: Generally, pack in rolls or wooden drums. Accept customized service for free.

Rolls, Wooden Drums, Steel Drums, Reels

Delivery: Both 20GP container and 40GP container are supplied.
Air transportation, Sea transportation, Express delivery.

Our Factory

00:0

Chunbin Cable Group Co.,Ltd. was founded in 1989.it has five core subsidiaries,including copper processing,PVC cable pellets production and more than 50 cooperative enterprises,With more than 600 sales outlets nationwide.It is a specialized company integrating R&D manufacturing and sales.

Our company mainly produces:mineral insulated cable,photovoltaic cablecharging pile cable,OPLC rail transit cable, optical fiber composite cable, medium and low voltage XLPE insulated power cable, pvc insulated power cable,aluminum alloy cable,fire resistant cable,flame retardant cable,control cable. overhead insulated cable, low-smoke halogen-free cable,rubbercable,mining cable,aluminum stranded wire and steel core aluminum stranded wire,PVC insulated wire and cord,shielded monitoring line, protection More than 50 varieties, more than 1000 specifications,such as line,agricultural land embedding, anti-aging line, coaxial cable. At the same time, it can also produce British standard American standard and German standard wire and cable, and customize special type wire and cable for customers.

Certifications

Our company strictly controls the quality of products. The products have passed the inspections of the national , provincial and municipal quality supervision departments for many years, and successfully passed the Chinese state. These certifications includes compulsory product certification, coal mine safety certification, national industrial product production license and ISO9001 international quality management system certification. It has obtained the national certificate of use of flame retardant products and is qualified as a foreign trade operator.

FAQ

1.Are you a factory or trade company ?

We are a professional cable manufacturer with 31 years experience. The factory is located in Luoyang, Henan province, China.

2.Whether these products quality assured ?

Most of cables are certificated. Also, we have strict QC, all products are tested before delivery. Quality is assured.

3.When I want customized products, how to do?

Contacting our customers survice, we have a professional R&D team and quality inspection team that can customize products according to customer’s needs.

4.Can you send a sample for us to test?

If we have inventory, you can get 1-5meters sample for free, but freight cost need to be paid by your compony. If need a lot of samples , sample and freight cost have to be paid by your esteemed company. We will return the sample cost to you when we receiving your initial order.

5.If we want to purchase, how to pay ?

Generally we do T/T in 30% deposit before production, 70% balance against copy of B/L . Also payment terms are negotiable depending on customer’s request.

6.When you arrange delivery after we place an order ?

Normally,we will arrange delivery in 7-15 days after order , and negotiation is allowed according to your quantity.

7.After I pay, what about shipping method?

Goods can be delivered by air, by express or by sea; International Express as FEDEX, UPS, DHL, TNT; You can choose the best way as you wish.
