Product Details

Model NO.

NA2XSA2Y-S

Current

DC & AC

Insulation Material

XLPE

Sheath Material

XLPE/PE/PVC

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

ISO, CCC, CE

Model

Na2xsa2y-S

Brand

Xinfeng Cable

Use

Power Transmission

No. of Cores

1, 2, 3

Color Identification

Number

Voltage Rating

6-35kv

Insulation Type

PVC/PE/XLPE

Minimum Bending Radius

15 X Od

Conductors

Aluminum

Transport Package

Steel Frame Wooden Drum

Specification

Made by order

Trademark

XinFeng Cable

Origin

China

HS Code

854449

Production Capacity

4500ton/Month

Packaging & Delivery

Package Size

10.00cm * 10.00cm * 10.00cm

Package Gross Weight

10.000kg

Product Description

1. Main Application
The cables are suitable for MV power applications, particularly for connections in transformer stations and power stations, between aerial lines and transformer stations. Aerial Bundle Cable, abbreviated as ABC, are wrapped with insulation, with the medium voltage variants also having an outer sheath. The cables lay up and twist multiple insulated single cores together – medium voltage ABC also tend to have a steel wire support running through the center for applications including street lighting and secondary pole to pole service cables. The cables also often used in temporary power installations in the construction industry. The insulation provides a protective barrier in the event of sparks or shorts.

2. Standards
IEC60502-2, AS/NZS 3599-1, AS/NZS 3599-2, GB/T14049 etc.
* Xinfeng Cable can also design and produce for special application requirement.

3. Characteristics
Voltage rating: 6kV-46kV

Operating temperature:
PVC: -15°C to +70°C PE: -40°C to +70°C XLPE: -40°C to +90°C

Minimum laying/installation temperature:
PVC: 0°C PE: -20°C XLPE: -20°C

4. Construction:
Type 1:

1: Conductors: CU/AAC/AAAC/ACSR.
2: Conductor screen: Extruded semi-conductive compound
3: Insulation: XLPE, UV-resistant.

Type 2:

1: Phase conductor: Circular compacted stranded aluminum
2: Conductor screen layer: Extruded semi-conductive compound.
3: Insulation: XLPE
4: Insulation screen layer: Extruded semi-conductive compound.
5: Separator layer: non-hygroscopic tape.
6: Outer sheath (optional): PE/XLPE/PVC, UV-resistant.
7: Support conductor: Stranded galvanized steel wires or aluminum alloy wires
Core identification (optional): Colors tape or numbers.
Assembly: Three XLPE insulated screened cores are bundled around the galvanized steel wires in a right hand lay.
Note: Support conductor could be with or without insulation.

If the cable model you want is not in the list, please contact our sales team to get more. For full technical specifications and for details of the bare conductor, please refer to the datasheets or speak to our sales team for more advice.

5. Product Type Description:

Description	Chinese type	International type
Aluminum conductor XLPE insulated aerial cable	JKLYJ/Q*	AAC/XLPE
Aluminum alloy conductor XLPE insulated aerial cable	JKLHYJ/Q*	AAAC/XLPE
Copper conductor XLPE insulated aerial cable	JKYJ	CU/XLPE
Aluminum conductor XLPE insulated aerial cable	JKLYJ	AAC/XLPE
Aluminum alloy conductor XLPE insulated aerial cable	JKLHYJ	AAAC/XLPE
Aluminum Conductor Steel Reinforced core XLPE insulated aerial cable	JKLGYJ JKLGYJ/Q*	ACSR/XLPE

Note: *: With Q Light type, without conductor screen.

6.Part Of Technical Parameter
Type 1:

Type	Nom. Conductor Cross Section mm²	Max.DC Conductor Resistance At 20ºC Ω/km	Approx.Min Thickness Conductor Screen mm	Nom. Thickness Of Insulation mm	Approx. OD mm	Approx. Weight kg/km	Minimum Breaking Load N	Current-Carrying Capacity A
CU/XLPE -35	50	0.399	0.5	9.3	27.9	964	16502	275
	70	0.276	0.5	9.3	29.6	1186	23461	345
	95	0.199	0.6	9.3	31.4	1458	31759	415
	120	0.158	0.6	9.3	32.8	1747	39911	480
	150	0.128	0.6	9.3	34.4	2015	49505	550
	185	0.1021	0.6	9.3	35.9	2320	61846	630
	240	0.0777	0.6	9.3	38.2	2896	79823	745
	300	0.0619	0.6	9.3	40.5	3479	99788	860
AAC/XLPE -35	50	0.641	0.5	9.3	27.9	664	7011	215
	70	0.443	0.5	9.3	29.6	767	10345	265
	95	0.320	0.6	9.3	31.4	889	13727	325
	120	0.253	0.6	9.3	32.8	996	17339	375
	150	0.206	0.6	9.3	34.4	1122	21033	425
	185	0.164	0.6	9.3	35.9	1247	26732	490
	240	0.125	0.6	9.3	38.2	1472	34679	580
	300	0.100	0.6	9.3	40.5	1698	43349	665
AAAC/XLPE -35	50	0.744	0.5	9.3	27.9	664	12569	210
	70	0.514	0.5	9.3	29.6	767	17396	250
	95	0.371	0.6	9.3	31.4	889	23886	315
	120	0.294	0.6	9.3	32.8	996	30164	365
	150	0.239	0.6	9.3	34.4	1122	37706	410
	185	0.19	0.6	9.3	35.9	1247	46503	485
	240	0.145	0.6	9.3	38.2	1472	60329	565
	300	0.11	0.6	9.3	40.5	1698	75411	650

Note: Current-carrying capacity (A) : ambient temperature 25°C.
Type 2:
6.35/11(12) kV Aerial Bundled Cable metallic screened, AL/XLPE/CTS/PVC AS/NZS 3599.1

Number of cores x nominal cross section No.×mm²	Phase conductor				Messenger conductor (Bare)			Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Number of cores x nominal cross section No.×mm²	Stranding No.×mm	Nominal diameter of conductor mm	Nom. thickness of insulation mm	Maximum conductor resistance at 20°C Ω/km	Stranding No.×mm	Nominal sectional area mm²	Minimum breaking load kN	Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
3X50 + 1X50	7/3.05	8.1	3.4	0.641	7/3.00	50	60	46	2200	116
3X70 + 1X50	19/2.22	9.8	3.4	0.443	7/3.00	50	60	49	2500	173
3X95+ 1X50	19/2.55	11.4	3.4	0.320	7/3.00	50	60	52	2850	210
3X120 +1X50	19/2.85	12.8	3.4	0.253	7/3.00	50	60	55	3160	259
3X150 +1X50	19/3.15	14.4	3.4	0.206	7/3.00	50	60	58	3560	259
3X185+1X50	36/2.52	16.0	3.4	0.164	7/3.00	50	60	61	3990	365
3X240 +1X50	36/2.88	18.4	3.4	0.125	7/3.00	50	60	66	4710	500

12.7/22(24) kV Aerial Bundled Cable metallic screened, AL/XLPE/CTS/PVC AS/NZS 3599.1

Number of cores x nominal cross section No.×mm²	Phase conductor				Messenger conductor (Bare)			Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Number of cores x nominal cross section No.×mm²	Stranding No.×mm	Nominal diameter of conductor mm	Nom. thickness of insulation mm	Maximum conductor resistance at 20°C Ω/km	Stranding No.×mm	Nominal sectional area mm²	Minimum breaking load kN	Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
3X50 + 1X50	7/3.05	8.1	5.5	0.641	7/3.00	50	60	54	2746	116
3X70 + 1X50	19/2.22	9.8	5.5	0.443	7/3.00	50	60	57	3133	173
3X95+ 1X50	19/2.55	11.4	5.5	0.320	7/3.00	50	60	60	3513	210
3X120 +1X50	19/2.85	12.8	5.5	0.253	7/3.00	50	60	63	3900	259
3X150 +1X50	19/3.15	14.4	5.5	0.206	7/3.00	50	60	66	4300	259
3X185+1X50	36/2.52	16.0	5.5	0.164	7/3.00	50	60	69	4805	365
3X240 +1X50	36/2.88	18.4	5.5	0.125	7/3.00	50	60	74	5600	500

19/33(36) kV Aerial Bundled Cable metallic screened, AL/XLPE/CTS/PVC AS/NZS 3599.1

Number of cores x nominal cross section No.×mm²	Phase conductor				Messenger conductor (Bare)			Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Number of cores x nominal cross section No.×mm²	Stranding No.×mm	Nominal diameter of conductor mm	Nom. thickness of insulation mm	Maximum conductor resistance at 20°C Ω/km	Stranding No.×mm	Nominal sectional area mm²	Minimum breaking load kN	Approx. OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
3X50 + 1X50	7/3.05	8.1	8.0	0.641	7/3.00	50	60	64	3610	116
3X70 + 1X50	19/2.22	9.8	8.0	0.443	7/3.00	50	60	67	4016	173
3X95+ 1X50	19/2.55	11.4	8.0	0.320	7/3.00	50	60	70	4486	210
3X120 +1X50	19/2.85	12.8	8.0	0.253	7/3.00	50	60	73	4854	259
3X150 +1X50	19/3.15	14.4	8.0	0.206	7/3.00	50	60	76	5358	259
3X185+1X50	36/2.52	16.0	8.0	0.164	7/3.00	50	60	79	5912	365
3X240 +1X50	36/2.88	18.4	8.0	0.125	7/3.00	50	60	83	6710	500

6.35/11(12) kV Aerial Bundled Cable non-screened, Al/XLPE/HDPE AS/NZS 3599.2

Number of cores x nominal cross section No.×mm²	Phase conductor					Messenger conductor(Bare)		Approx. completed cable OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Number of cores x nominal cross section No.×mm²	Nominal diameter of conductor mm	Nominal thickness of insulation mm	Nominal thickness of insulation screen mm	Nominal thickness of sheath mm	Maximum conductor resistance at 20°C Ω/km	Stranding No.×mm	Approx. OD mm	Approx. completed cable OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
3×35	6.9	3.4	0.6	1.2	0.868	7/5.00	15.0	52.3	1470	165
3×50	8.1	3.4	0.6	1.2	0.641	7/5.00	15.0	53.5	1580	200
3×70	9.8	3.4	0.6	1.2	0.443	7/5.00	15.0	56.7	1850	245
3×95	11.4	3.4	0.6	1.2	0.320	7/5.00	15.0	60.2	2180	300
3×120	12.8	3.4	0.6	1.2	0.253	19/3.65	18.2	66.2	2640	345
3×150	14.4	3.4	0.6	1.2	0.206	19/3.65	18.2	69.0	2960	390
3×185	16.0	3.4	0.6	1.2	0.164	19/3.65	18.2	72.4	3380	450

12.7/22(24) kV Aerial Bundled Cable metallic screened Al/XLPE/CWS/HDPE AS/NZS 3599.1

Number of cores x nominal cross section No.×mm²	Phase Conductor						Messenger conductor(Bare)		Approx. completed cable OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Number of cores x nominal cross section No.×mm²	Nominal diameter of conductor mm	Nominal thickness of insulation mm	Nominal thickness of insulation screen mm	Nominal thickness of sheath mm	Maximum conductor resistance at 20°C Ω/km	Copper wire screen No.×mm	Stranding No.×mm	Approx. OD mm	Approx. completed cable OD mm	Approx. weight kg/km	Continuous current rating at 40ºC ambient temp A
Light duty screen
3×35	6.9	5.5	0.6	1.8	0.868	25/0.85	7/2.00	6.0	62.8	2340	150
3×50	8.1	5.5	0.6	1.8	0.641	25/0.85	19/2.00	10.0	68.5	2780	185
3×70	9.8	5.5	0.6	1.8	0.443	25/0.85	19/2.00	10.0	71.8	3100	230
3×95	11.4	5.5	0.6	1.9	0.320	25/0.85	19/2.00	10.0	75.6	3510	280
3×120	12.8	5.5	0.6	1.9	0.253	25/0.85	19/2.00	10.0	78.6	3850	320
3×150	14.4	5.5	0.6	2.0	0.206	25/0.85	19/2.00	10.0	81.8	4240	365
3×185	16.0	5.5	0.6	2.0	0.164	25/0.85	19/2.00	10.0	85.2	4710	415
Heavy duty screen
3×35	6.9	5.5	0.6	1.8	0.868	40/0.85	7/2.00	6.0	62.8	2600	155
3×50	8.1	5.5	0.6	1.8	0.641	23/1.35	19/2.00	10.0	70.5	3350	185
3×70	9.8	5.5	0.6	1.8	0.443	32/1.35	19/2.00	10.0	73.8	4030	230
3×95	11.4	5.5	0.6	1.9	0.320	38/1.35	19/2.00	10.0	77.6	4680	280
3×120	12.8	5.5	0.6	1.9	0.253	38/1.35	19/2.00	10.0	80.6	5020	320
3×150	14.4	5.5	0.6	2.0	0.206	38/1.35	19/2.00	10.0	83.8	5410	365
3×185	16.0	5.5	0.6	2.0	0.164	38/1.35	19/2.00	10.0	87.2	5880	415

Packaging Mode 1:Wooden Drum Packing,suitable for small cross section cable.Packing length about 500 meters.
Packaging Mode 2:Steel Frame Wooden Drum Packing,suitable for big cross section cable.Packing length about 2000 meters.
