0.6/1kv Concentric Cable 2*4mm2 Negro

0.6/1kv Concentric Cable 2*4mm2 Negro image

Get Latest Price Request a quote

Product Details

Model NO.

YJV72

Current

AC Cable

Insulation Material

XLPE

Sheath Material

Crosslinking

Material Shape

Flat Wire

Wire Core Material

Tinned Wire

Certification

ISO, CCC, CE, RoHS, VDE

Model

Yjv32

Brand

Jinshui

Transport Package

Wooden Drums

Specification

2.2*1.1*1.0*1.1

Trademark

Jinshui

Origin

China

HS Code

8544492100

Production Capacity

50000m/Day

Product Description

Application:Concentric cables are commonly used for power distribution network, ammeter panel, instrument or circuit panel, which can be laid directly underground or outdoors and even applicable in dry and wet conditions.
Standard:
IEC60502-1, BS7870, ASTMD2655,ASTMB556, ASTMB193, ASTMB8, UL44, UL1581, UL854
Specification:
Rated Voltage:0.6/1kV
Maximal short-circuit temperature:+250 ºC
Minimum installation temperature: -20ºC
Max. conductor temp.in service:XLPE-90 ºC ,PVC-70 ºC
Outer sheath— UV resistant

Construction:

Conductor: Class 2 copper conductor
Insulation: XLPE /PVC insulation
Concentric layer: Copper wires
Cable wrapping tape: Non-absorbent material
Cable sheath: PVC (XLPE/PE) sheath

PARAMETERS

Single conductor type concentric cable (Coverage<100%)
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Concentric conductor		Overall jacket nominal thickness	Approx. overall diameter	Approx. weight.	DC resistance at 20ºC
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Min. single wire dia.	Max. wire number	Overall jacket nominal thickness	Approx. overall diameter	Approx. weight.	DC resistance at 20ºC
mm²	AWG	Nos	mm	mm	Nos	mm	mm	kg/km	Ω/KM
2.08	14	7	1.14	0.51	68	1.14	7.8	73	8.78
2.63	13	7	1.14	0.51	68	1.14	8.06	84	6.97
3.31	12	7	1.14	0.51	68	1.14	8.26	98	5.53
4.17	11	7	1.14	0.51	68	1.14	8.54	116	4.39
5.26	10	7	1.14	0.51	68	1.14	8.86	138	3.476
8.37	8	7	1.14	0.51	68	1.14	9.55	197	2.186

Tow conductor type concentric cable (Coverage<100%)
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Concentric conductor		Jacket nominal thickness	Approx. overall dia.	Approx. weight.	Max.DC resistance at 20ºC
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Min. single wire dia.	Max. wire number	Jacket nominal thickness	Approx. overall dia.	Approx. weight.	Max.DC resistance at 20ºC
mm2	AWG	No.s	mm	mm	No.s	mm	mm	kg/km	Ω/KM
5.26	10	7	1.14	0.51	96	1.14	15.3×10.1	262	3.476
8.37	8	7	1.52	0.51	96	1.52	19.2×12.5	411	2.186
13.3	6	7	1.52	0.51	96	1.52	21.2×13.5	574	1.375
21.15	4	7	1.52	0.51	96	2.03	25.0×16.0	856	0.8649
26.67	3	7	1.52	0.51	96	2.03	26.6×17.0	1030	0.686
33.62	2	7	1.52	0.51	96	2.03	28.4×17.9	1247	0.544

Two conductor type(flat) concentric cable (Coverage<100%)
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Concentric conductor		Jacket nominal thickness	Approx. overall dia.	Approx. weight.	DC resistance at 20ºC
Nominal cross-section		Strands number of conductor	Insulation nominal thickness	Min.single wire dia.	Max.wire number	Jacket nominal thickness	Approx. overall dia.	Approx. weight.	DC resistance at 20ºC
mm2	AWG	No.s	mm	mm	No.s	mm	mm	kg/km	Ω/KM
2.08	14	7	1.14	0.51	96	1.14	13.3×9.1	154	8.78
2.63	13	7	1.14	0.51	96	1.14	13.7×9.3	173	6.97
3.31	12	7	1.14	0.51	96	1.14	14.1×9.5	196	5.53
4.17	11	7	1.14	0.51	96	1.14	14.6×9.8	226	4.39
5.26	10	7	1.14	0.51	96	1.14	15.3×10.1	262	3.476
6.63	9	7	1.14	0.51	96	1.52	18.4×12.0	351	2.758
8.37	8	7	1.14	0.51	96	1.52	19.2×12.5	411	2.186
10.55	7	7	1.52	0.51	96	1.52	20.2×13.0	485	1.734
13.3	6	7	1.52	0.51	96	1.52	21.2×13.5	574	1.375
16.77	5	7	1.52	0.51	96	2.03	23.6×15.3	718	1.091
21.15	4	7	1.52	0.51	96	2.03	25.0×16.0	856	0.8649
26.67	3	7	1.52	0.51	96	2.03	26.6×17.0	1030	0.686
33.62	2	7	1.52	0.51	96	2.03	28.4×17.9	1247	0.544
42.41	1	19	2.03	0.51	96	2.03	32.9×20.3	1589	0.4313
53.49	1/0	19	2.03	0.51	96	2.03	35.1×21.6	1929	0.3419
67.43	2/0	19	2.03	0.51	96	2.03	37.8×23.1	2358	0.2712
85.01	3/0	19	2.03	0.51	96	2.03	40.7×24.7	2888	0.2151
107.2	4/0	19	2.03	0.51	96	2.03	44.0×26.5	3551	0.1705

Core and nominal cross section	Conductor		Insulation thickness	Concentric conductor		Thickness of cable shield	.	Weight of cable/km	Max DC resistance of conductor (20ºC)
mm2	Number	Diameter mm	mm	Number	Diameter mm	mm	mm	kg/km	Ω/km ()	Ω/km (Concentric)
Copper conductor (IEC standard)
2X10	7	1.35	1.55	20	0.85	1.40	11.80	290	1.83	1.90
2X16	7	1.70	1.55	32	0.85	1.40	12.84	420	1.15	1.20
2X25	7	2.14	1.60	29	1.13	1.50	15.02	630	0.727	0.76
2X35	19	1.53	1.65	27	1.35	1.60	17.00	832	0.524	0.55

We are China 0.6/1kv Concentric Cable 2*4mm2 Negro manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
