0.6/1kv Aluminum Conductor PVC Insulation PVC Sheath Electrical Power Cable

0.6/1kv Aluminum Conductor PVC Insulation PVC Sheath Electrical Power Cable image

Get Latest Price Request a quote

Product Details

Model NO.

Power Cable

Current

DC & AC

Insulation Material

PVC

Sheath Material

PVC

Material Shape

Round Wire

Wire Core Material

Aluminum

Certification

ISO, CCC, CE, RoHS

Model

Brand

Hnbf Cable

Colour

Red, Black, Yellow, Green, Blue...

Armour

Steel Wire Armour or Steel Tape Armour or Unarmour

No.Cores

1,2,3....

Transport Package

Fumigated Wooden Drum

Specification

16mm2, 25mm2, 35mm2, 50mm2, 70mm2

Trademark

HNBF Cable

Origin

China

HS Code

8544492100

Production Capacity

2500km/Month

Product Description

Product Description & Application

A power cable is an assembly of one or more electrical conductors, usually held together with an overall sheath. The assembly is used for transmission of electrical power. Power cables may be installed as permanent wiring within buildings, buried in the ground, run overhead, or exposed.
It is used to transmit and distribute power in power transmission and distribution system of 0.6/1kV to 8.7/15kV. It is generally applied to the fields including power, construction, mines, metallurgy, petrochemical industry and communication.

Technincal Data

Operating Features

1)Operating temperature
Max. Permissible continuous operating temperature of Conductors shall not exceed 90ºC
2)Conductor Short circuit temperature
Not exceeding 250 . (Max. Duration 5 seconds)
3)Bending radius:
Bending radius of single core cable:20D Bending radius of multi-core cable: 15D
D=Actual overall diameter of cable (mm)
4)Installation temperature:
The lowest temperature of installation is 0ºC .
Laying conditions and basic parameters for calculating current ratings:
Method of laying: Ambient temperature
In air: 40ºC Direct burial: 25ºC Soil thermal resistivity 1.0ºC· m/W
Layout of single core cables: In parallel (Spacing side by side: 1D D=overall diameter)

1. Conductor 2. Conductor Screen 3. XLPE Insulation 4. Insulation screen

5. Metallic Screen 6. Filler 7. Separator(Inner Cover) 9. Outer Sheath

Our Certifications

Detailed Images

Our Company

Why Choose Us

1. Strict quality control system, excellent quality with reasonable price.

2. Strong and Professional R&D team to meet your specific needs.

3. Rapid delivery and feedback. Faster lead time than our competitors.

4. OEM service available based on official & legal authorization.

5. Free sample is available.

6. Appointed shipping company is acceptable.

Packing & Delivery

We are China 0.6/1kv Aluminum Conductor PVC Insulation PVC Sheath Electrical Power Cable manufacture and supplier,You can get more details with Email,you will get cheap price or factory price.
